Machine Id: 860 Serial No:
Model: SH 100 (with internal head) Asking Price: onrequest
Make: Maag Country: Switzerland
Year: 1981 Weight: 0.0
Dimensions: Location: mumbai warehouse,India
Power:
Category: Gear Shapers
Type of Machine: universal gear shaper with 345mm stroke and internal head
Specification

Max wheel Ø 1200 mm
Module + 15
Module - 2
Max. spindle speed
Max. gear width 320 mm
Motor power
-------------------
Length x width x height 3300 mm × 2200 mm × 2800 mm
Weight 9000 kg
Worked power hours
State good
At local norms ---------
Status visible

Description


Tooth width - helical gear - 15 degrees 290 mm
tooth width - helical gear - 30 degrees 255 mm
tooth width - helical gear - 45 degrees 200 mm
ram stroke range 8,6 - 33,8 Hub/min
down feeds 43,2 - 110 mm/Hub
rotary feeds 9-80 Hub/Tlg.
electrics - voltage/frequency 380/50 V/Hz
total power requirement 16 PS
weight of the machine ca. 9 t
dimensions of the machine ca. 3,3 x 2,2 x 2,8 m
