Working width of the table 400 mm
Hole dia of the table 140H7 mm
Face plate dia 250 mm
Hole face plate dia 100 mm
Max pull-broach length 1400 mm
Min pull-broach length 600 mm
Max pull-broach dia 95 mm
Work stroke speed range 1,5-11,5 m/min
Fast stroke 20 m/min
Feeding speed of the pull broach 15 m/min
Reversing speed of the speed broach 11 m/min
Speed regulation of the main drive stepless
Main drive hydraulic
